The FMS system enables the continuous measurement of actual lateral guiding forces during operation, providing valuable insights into crane behavior and rail system conditions. By converting mechanical loads into standardized 4–20 mA signals, the system delivers reliable real-time data for advanced condition monitoring and predictive maintenance strategies.
Measurement data can be directly evaluated by the crane control system (PLC), allowing operators to continuously monitor operating conditions and identify abnormalities at an early stage.
- Continuous live measurement of actual lateral guiding forces during operation
- Precise conversion of mechanical loads into standardized 4–20 mA output signals
- Real-time data availability for data-driven condition monitoring
- Seamless integration of measurement results into the crane PLC
- Early detection of wear in the rail system to help prevent unplanned crane downtime
- Factory calibration under realistic installation conditions for maximum measurement accuracy
- Robust industrial-grade sensor design for harsh operating environments
- Easy retrofit installation on existing systems
- Measurement range: 0 – 450 kN
- Signal measurement range: 4 – 20 mA
- Kind of loading: Compression
- Nominal load: 450 kN
- Max. load: 120 %
- Breaking load: 180 %
- Operating temperature: -40 bis 80 °C
- Protection class: IP66/IP67
- Mining & Material handling
- Crane technology
- Bridge/Sluice systems
- Storage technology
- Offshore/Ship
- Railbound hall roofs and gates
- Steel industry
